Developer Guide for Foxit PDF SDK for Android (7.1)

Contents

Introduction to Foxit PDF SDK
Getting Started
Rapidly building a full-featured PDF Reader
Customizing User Interface
Working with SDK API
Creating a custom tool
Implement Foxit PDF SDK for Android using Cordova
Implement Foxit PDF SDK for Android using React Native
Implement Foxit PDF SDK for Android using Xamarin
FAQ
Technical Support

Introduction to Foxit PDF SDK

Foxit PDF SDK

Foxit PDF SDK provides high-performance libraries to help any software developer add robust PDF functionality to their enterprise, mobile and cloud applications across all platforms (includes Windows, Mac, Linux, Web, Android, iOS, and UWP), using the most popular development languages and environments.

Application developers who use Foxit PDF SDK can leverage Foxit’s powerful, standard-compliant PDF technology to securely display, create, edit, annotate, format, organize, print, share, secure, search documents as well as to fill PDF forms. Additionally, Foxit PDF SDK includes a built-in, embeddable PDF Viewer, making the development process easier and faster. For more detailed information, please visit the website https://developers.foxit.com/pdf-sdk/.

In this guide, we focus on the introduction of Foxit PDF SDK for Android platform.

Foxit PDF SDK for Android

Have you ever worried about the complexity of the PDF specification? Or have you ever felt lost when asked to build a full-featured PDF app within a limited time-frame? If your answer is “Yes”, then congratulations! You have just found the best solution in the industry for rapidly integrating PDF functionality into your apps.

Foxit PDF SDK for Android focuses on helping developers easily integrate powerful Foxit PDF technology into their own mobile apps. With this SDK, even developers with a limited knowledge of PDF can quickly build a professional PDF viewer with just a few lines of code on Android platform.

Why Foxit PDF SDK for Android is your choice

Foxit is a leading software provider of solutions for reading, editing, creating, organizing, and securing PDF documents. Foxit PDF SDK libraries have been used in many of today’s leading apps, and they are proven, robust, and battle-tested to provide the quality, performance, and features that the industry’s largest apps demand.

Foxit PDF SDK for Android provides quick PDF viewing and manipulation support for Android Devices. Customers choose it for the following reasons:

Easy to integrate

Developers can seamlessly integrate the SDK into their own apps with just a few lines of code.

Perfectly designed

Foxit PDF SDK for Android is designed with a simple, clean, and friendly style, which provide the best user experience.

Flexible customization

Foxit PDF SDK for Android provides the source code for the user interface which lets the developers have full control of the functionality and appearance of their apps.

Robust performance on mobile platforms

Foxit PDF SDK for Android provides an OOM (out-of-memory) recovery mechanism to ensure the app has high robust performance when running the app on a mobile device which offers limited memory.

The core technology of the SDK is based on Foxit’s PDF engine, which is trusted by a large number of the world’s largest and well-known companies. Foxit’s powerful engine makes the app fast on parsing, rendering, and makes document viewing consistent on a variety of devices.

Premium World-side Support

Foxit offers premium support for its developer products because when you are developing mission critical products you need the best support. Foxit has one of the PDF industry’s largest team of support engineers. Updates are released on a regular basis to improve user experience by adding new features and enhancements.

Main Frame of Foxit PDF SDK for Android

Foxit PDF SDK for Android consists of three elements as shown in the following picture. This structure is shared between all mobile platform versions of Foxit PDF SDK, which makes it easier to integrate and support multiple mobile operating systems and frameworks in your apps.

The three elements of Foxit PDF SDK for Android, iOS and UWP

PDF Core API

The PDF Core API is the heart of this SDK and is built on Foxit’s powerful underlying technology. It provides the functionality for basic PDF operation features, and is utilized by the PDF View Control and UI Extensions Component, which ensures the apps can achieve high performance and efficiency. The Core API can be used independently for document rendering, analysis, text extraction, text search, form filling, digital signatures, Pressure Sensitive Ink, certificate and password security, annotation creation and manipulation and much more.

PDF View Control

The PDF View Control is a utility class that provides the functionality for developers to interact with rendering PDF documents per their requirements. With Foxit’s renowned and widely used PDF rendering technology at its core, the View Control provides fast and high quality rendering, zooming, scrolling and page navigation features. The View Control derives from platform related viewer classes such as Android.View.ViewGroup and allows for extension to accommodate specific user needs.

UI Extensions Component

The UI Extensions Component is an open source library that provides a customizable user interface with built-in support for text selection, markup annotation, outline navigation, reading bookmarks, full-text searching, form filling, text reflow, attachment, digital/handwritten signature, document editing and password encryption. These features in the UI Extensions Component are implemented using the PDF Core API and PDF View Control. Developers can utilize these ready-to-use UI implementations to build a PDF viewer quickly with the added benefit of complete flexibility and control to customize the UI design as desired.

From version 4.0, Foxit PDF SDK for Android made a big change and optimization for the UI Extensions Component. Now, it wraps the basic UI implementations to PDFReader class, such as panel controller, toolbar settings, and alert view, etc. Building a full-featured PDF Reader is getting simpler and easier. Furthermore, users can flexibly customize the features they want through a configuration file.

From version 5.0, every element in the built-in UI can be configurable through an API. More advanced APIs and more powerful configuration file are provided for developers to further customize the UI elements, such as adding/removing a button to/from the toolbar, showing/hiding a specific menu/function panel, and etc.

From version 6.0, Foxit PDF SDK for Android removed the PDFReader class and moved the wrapped APIs in PDFReader class to UI Extensions Component.

UI Extensions Component Overview

The UI Extensions Component uses “module” mechanism which refines each feature into a module. All of the modules except LocalModule (used for file management) will be loaded by default if UI Extensions is added. Users can customize module through implementing Module interface class, and then call UIExtensionsManager#registerModule to register the custom module to current UIExtensions manager. When not in use, you can call UIExtensionsManager#unregisterModule to unregister it from current UIExtensions manager.

UIExtensionsManager contains the main-frame UI, such as top/bottom toolbar, and other UI components which are shared between each module. Meanwhile, through UIExtensionsManager, each feature module can also be loaded separately. And when loaded, the feature module will adapt and adjust the main-frame UI, as well as establish the connection of message event response. Each feature module may contain its module-specific UI components, and have its self-contained message event handling logic. UIExtensionsManager will also be responsible for distributing messages and events received from View Control component to each feature module. The following figure shows the detailed relationship between UIExtensionsManager and modules.

The relationship between UIExtensionsManager and modules

Tool handler and annotation handler will process the events from touch screen or gestures of PDFViewCtrl. When the touch screen and gestures occur, PDFViewCtrl will send the corresponding events to UIExtensionsManager:

a) If a tool handler exists currently, UIExtensionsManager will send the corresponding events to the current tool handler, and then event-handing process ends.

b) If an annotation is selected currently, UIExtensionsManager will send the corresponding events to the annotation handler corresponding to the currently selected annotation, and then event-handing process ends.

c) If currently no tool handler exists and no annotation is selected, UIExtensionsManager will send the corresponding events to selection tool handler. Text Selection tool is used for processing the related events for text selection. For example, select a piece of text, and add Highlight annotation. Blank Selection tool is used for processing the related events for blank space. For example, add a Note annotation on the blank space.

Note: Tool Handler and Annotation Handler will not respond the events at the same time. Tool Handler is primarily used for annotation creation (currently, the creation of link annotation is not supported), signature creation and text selection. Annotation Handler is mainly used for annotation editing and form filling. The following figure shows the event response flow chart between Tool Handler and Annotation Handler.

The event response flow chart between Tool Handler and Annotation Handler

Key Features of Foxit PDF SDK for Android

Foxit PDF SDK for Android has several main features which help app developers quickly implement the functions that they really need and reduce the development cost.

Features
PDF Document	Open and close files, set and get metadata.
PDF Page	Parse, render, read, and edit PDF pages.
Render	Graphics engine created on a bitmap for platform graphics device.
Reflow	Rearrange page content.
Crop	Crop PDF pages for betting reading.
Text Select	Select text in a PDF document.
Text Search	Search text in a PDF document, and provide indexed Full-Text Search.
Outline	Directly locate and link to point of interest within a document.
Reading Bookmark	Mark progress and interesting passages as users read.
Annotation	Create, edit and remove annotations.
Layers	Add, edit, and remove optional content groups.
Attachments	Add, edit, and remove document level attachments.
Form	Fill form with JavaScript support, export and import form data by XFDF/FDF/XML file.
XFA	Support static and dynamic XFA.
Signature	Sign a PDF document, verify a signature, add or delete a signature field. Add and verify third-party digital signature. Support Long term validation of signatures (LTV).
Security	Protect PDFs with password or certificate.
Pan and Zoom	Adjust the magnification and position of the view area to match the area in an adjustable rectangle in the Pan & Zoom window’s thumbnail view of the page.
Print	Print PDF document.
RMS	Support Microsoft RMS decryption with the standard IRMv1 and IRMv2.
Comparison	Compare two PDF documents, and mark the differences between them.
Out of Memory	Recover from an OOM condition.

Note Outline is the technical term used in the PDF specification for what is commonly known as bookmarks in traditional desktop PDF viewers. Reading bookmarks are commonly used on mobile and tablet PDF viewers to mark progress and interesting passages as users read but are not technically outline and are stored at app level rather than within the PDF itself.

Support robust PDF applications with Foxit PDF SDK for Android

Development of robust PDF applications is challenging on mobile platforms which has limited memory. When memory allocation fails, applications may crash or exit unexpectedly. To deal with this issue, Foxit PDF SDK for Android provides an out-of-memory (OOM) mechanism to support applications.

OOM is an evolved feature in Foxit PDF SDK for Android because of its complexity. The key of OOM mechanism is that Foxit PDF SDK for Android will monitor the usage of memory and take recovery operations automatically once OOM is detected. During the recovery process, Foxit PDF SDK for Android reloads the document and page automatically and restores the status to the original before OOM. It means the current reading page and location, as well as page view mode (single or continuous page) can be recovered. However, the data generated from editing will be lost.

Foxit PDF SDK for Android provides a property “shouldRecover” in PDFViewCtrl class. By default, the value of “shouldRecover” is “true“. If you do not want to enable the auto-recovery when OOM is detected, you can set “shouldRecover” to “false” as follows:

PDFViewCtrl pdfViewerCtrl = new PDFViewCtrl(getActivity().getApplicationContext());
pdfViewerCtrl.shouldRecover = false;

At that time, the application will throw an exception, and may crash or exit unexpectedly.

Evaluation

Foxit PDF SDK allows users to download trial version to evaluate SDK. The trial version has no difference from the standard licensed version except for the free 10-day trial limitation and the trial watermarks in the generated pages. After the evaluation period expires, customers should contact the Foxit sales team and purchase licenses to continue using Foxit PDF SDK.

License

Developers should purchase licenses to use Foxit PDF SDK in their solutions. Licenses grant developers permission to release their apps which utilize Foxit PDF SDK. However, users are prohibited to distribute any documents, sample code, or source code in the released package of Foxit PDF SDK to any third party without written permission from Foxit Software Incorporated.

About this Guide

This guide is intended for the developers who need to integrate Foxit PDF SDK for Android into their own apps. It aims at introducing the following sections:

Section 1: gives an introduction of Foxit PDF SDK, especially for Android platform SDK.
Section 2: illustrates the package structure and running demos.
Section 3: describes how to quickly create a full-featured PDF Reader.
Section 4: introduces how to customize the user interface.
Section 5: shows how to use Foxit PDF SDK Core API.
Section 6: shows how to create a custom tool.
Section 7: shows how to implement Foxit PDF SDK using Cordova
Section 8: shows how to implement Foxit PDF SDK using React Native
Section 9: shows how to implement Foxit PDF SDK using Xamarin
Section 10: lists some frequently asked questions.
Section 11: provides support information.

Getting Started

It is very easy to setup Foxit PDF SDK for Android and see it in action! It takes just a few minutes and we will show you how to use it on the Android platform. The following sections introduce the structure of the installation package and how to run a demo.

System Requirements

Android devices’ requirements:

Android 4.1 (API 16) or higher
32/64-bit ARM (armeabi-v7a/arm64-v8a) or 32/64-bit Intel x86 CPU

Android Studio 3.0 or newer

The runtime environment for our demos:

Android Studio 3.1
JDK 1.8
Gradle Version 4.4
Gradle Build Tool 3.1

What is in the Package

Download the “foxitpdfsdk_7_1_android.zip” package, and extract it to a new directory like “foxitpdfsdk_7_1_android” as shown in Figure 2-1. The package contains:

docs:	A folder containing API references, developer guide, and upgrade warnings.
libs:	A folder containing license files, AAR files, and UI Extensions Component source code.
samples:	A folder containing Android sample projects.
getting_started_android.pdf:	A quick guide for Foxit PDF SDK for Android.
legal.txt:	Legal and copyright information.
release_notes.txt:	Release information.

Figure 2-1

In the “libs” folder as shown in Figure 2-2, there are items that make up the core components of Foxit PDF SDK for Android, and third-party libraries used for Microsoft RMS support.

Figure 2-2

uiextensions_src project – found in the “libs” folder. It is an open source library that contains some ready-to-use UI module implementations, which can help developers rapidly embed a fully functional PDF reader into their Android app. Of course, developers are not forced to use the default UI, they can freely customize and design the UI for their specific apps through the “uiextensions_src” project.
FoxitRDK.aar – contains JAR package which includes all the Java APIs of Foxit PDF SDK for Android, as well as the underlying “.so” libraries. The “.so” library is the heart of the SDK including the core functionalities of Foxit PDF SDK for Android. It is built separately for each architecture, and currently available for armeabi-v7a, arm64-v8a, x86, and x86_64.
FoxitRDKUIExtensions.aar – generated by the “uiextensions_src” project found in the “libs” folder. It includes the JAR package, built-in UI implementation, and resource files that are needed for the built-in UI implementations, such as images, strings, color values, layout files, and other Android UI resources.
RMSSDK-4.2-release.aar – used for creating rights-enabled applications. For more detailed information, please refer to https://www.microsoft.com/en-ie/download/details.aspx?id=43673.
rms-sdk-ui.aar – provides Android Activities that implement the UI required for the RMS SDK functionality. For more detailed information, please refer to https://github.com/AzureAD/rms-sdk-ui-for-android.

Note: In order to reduce the size of FoxitRDKUIExtensions.aar, Foxit PDF SDK for Android uses shrink-code in the uiextensions_src project. If you do not want to use shrink-code when you build the uiextensions_src project, you can disable it by setting “minifyEnabled“ to “false“ in the App’s build.gradle. For shrink-code, you can refer to https://developer.android.com/studio/build/shrink-code.html.

At this point you should just be getting a feel for what Foxit PDF SDK for Android package looks like, we’re going to cover everything in detail in a bit.

How to run a demo

Download and install Android Studio IDE (https://developer.android.com/studio/index.html).

Note: In this guide, we do not cover the installation of Android Studio, Android SDK, and JDK. You can refer to Android Studio’s developer site if you haven’t installed it already.

Foxit PDF SDK for Android provides three useful demos for developers to learn how to call the SDK as shown in Figure 2-3.

Figure 2-3

Function demo

The function demo is provided to show how to use Foxit PDF SDK for Android to realize some specific features related to PDF with PDF core API. This demo includes the following features:

pdf2txt: extract text from a PDF document to a TXT file.
outline: edit outline (aka bookmark) appearances and titles.
annotation: add annotations to a PDF page.
docinfo: export document information of a PDF to a TXT file.
render: render a specified page to Bitmap.
signature: add a signature to PDF, sign PDF and verify the signature.

To run it in Android Studio, follow the steps below:

a) Load the demo in Android Studio through “File -> New -> Import Project…” or “File -> Open…”, and then navigate to where the function_demo project is stored and select the function_demo folder. Continue with “OK”.

b) Launch an Android device or an emulator (AVD). In this section, an AVD targeting 8.1 will be used as an example. The test files in the “samples/test_files” that are needed for the demos will be copied to the emulator’s storage card automatically when running the demos.

c) Click on “Run -> Run ‘app'” to run the demo. After installing the APK on the emulator, tap Allow on the pop-up window to allow the demo to access files on the device. Then you can see the features are listed like Figure 2-4.

Figure 2-4

d) Click the feature buttons in the above picture to perform the corresponding actions. For example, click “pdf2txt”, and then a message box will be popped up as shown in Figure 2-5. It shows where the text file was saved to. Just run the demo and try the features.

Figure 2-5

Viewer control demo

The viewer control demo demonstrates how to implement the features related to the View Control feature level, such as performing annotations (note, highlight, underline, strikeout, squiggly, etc.), changing layout, text search, outline, and page thumbnail. The logical structure of the code is quite clear and simple so that developers can quickly find the detailed implementation of features which are used widely in PDF apps, such as a PDF viewer. With this demo, developers can take a closer look at the APIs provided in Foxit PDF SDK for Android.

To run the demo in Android Studio, please refer to the setup steps outlined in the Function demo.

Viewer control demo will not copy the test file to the Android device or emulator automatically. It will use the “Sample.pdf” (found in the “samples/test_files” folder) as the test file, so please make sure you have pushed this file into the created folder “input_files” (or “FoxitSDK”, which depends on the demo that you set) of Android device or emulator before running this demo.

Figure 2-6 shows what the demo looks like after it was built successfully. Here, an AVD targeting 8.1 will be used as an example to run the demo.

Figure 2-6

Click anywhere in the page, then the Contextual Action bar will appear, and you can click (overflow button) to see more action items as shown in Figure 2-7.

Figure 2-7

Now we can choose one item to perform the action and see the result. For example, click “Outline”, then you will see the outline (outline is the technical term for bookmark in the PDF specification) of the document as shown in Figure 2-8. Try using the other features to see it in action.

Figure 2-8

Complete PDF viewer demo

The complete PDF viewer demo demonstrates how to use Foxit PDF SDK for Android to realize a completely full-featured PDF viewer which is almost ready-to-use as a real world mobile PDF reader, and from version 6.0, it supported viewing multiple PDF documents. This demo utilizes all of the features and built-in UI implementations which are provided in Foxit PDF SDK for Android.

To run the demo in Android Studio, please refer to the setup steps outlined in the Function demo.

The “complete_pdf_viewer_guide_android.pdf” and “Sample.pdf” in “samples\complete_pdf_viewer\app\src\main\assets” will be copied to the “FoxitSDK” folder of the emulator automatically when running the demo.

Here, an AVD targeting 8.1 will also be used as an example to run the demo. After building the demo successfully, on the start screen, it lists the “complete_pdf_viewer_guide_android.pdf” and “Sample.pdf” documents. If you want to view multiple PDF documents, click to switch to the tabs reading mode (see Figure 2-9).

Note The “complete_pdf_viewer_guide_android.pdf” and “Sample.pdf” documents will be automatically deployed to your device so that you don’t need to push them into the device manually. But if you want to use some other PDF files to test this demo, you should push them into the device’s SD card.

Figure 2-9

Click YES to switch to the tabs reading mode. Select the “complete_pdf_viewer_guide_android.pdf” document, and then click the Back button, and select the “Sample.pdf”, then it will be displayed as shown in Figure 2-10. Now, you can browse the two PDF documents by switching the tabs.

Figure 2-10

This demo realizes a completely full-featured PDF viewer, please feel free to run it and try it.

For example, it provides the page thumbnail feature. You can click the View menu, choose the Thumbnail as shown in Figure 2-11, and then the thumbnail of the document will be displayed as shown in Figure 2-12.

Figure 2-11

Figure 2-12

Rapidly building a full-featured PDF Reader

Foxit PDF SDK for Android wrapped all of the UI implementations including the basic UI for app and ready-to-use UI feature modules to UI Extensions Component, so that developers can easily and rapidly build a full-featured PDF Reader with just a few lines of code. This section will help you to quickly get started with using Foxit PDF SDK for Android to make a full-featured PDF Reader app in Android platform with step-by-step instructions provided.

This section will help you to quickly make an Android app using Foxit PDF SDK for Android. It includes the following steps:

Create a new Android project
Integrate Foxit PDF SDK for Android into your apps
Initialize Foxit PDF SDK for Android
Display a PDF document using PDFViewCtrl
Open a RMS protected document
Build a full-featured PDF Reader with UI Extensions Component

Create a new Android project

In this guide, we use Android Studio 3.1.3 along with Android API revision 27.

Open Android Studio, choose File -> New -> New Project… to start the Create Android Project wizard, and then fill the New Project dialog as shown in Figure 3-1. After filling, click Next.

Figure 3-1

In the Target Android Devices dialog, set the minimum SDK to API 16. So choose “API 16: Android 4.1 (Jelly Bean)” from the drop-down list as shown in Figure 3-2. Then, click Next.

Figure 3-2

In the Add an Activity to Mobile dialog, select “Empty Activity” (for some other Android Studio versions, it might be “Blank Activity”) as shown in Figure 3-3, and then click Next.

Figure 3-3

In the Configure Activity dialog, customize your activity as desired. Here, we use the default settings as shown in Figure 3-4, and then click Finish.

Figure 3-4

Integrate Foxit PDF SDK for Android into your apps

Note: In this section, we will use the default built-in UI implementation to develop the app, for simplicity and convenience (use the UI Extensions Component directly, and don’t need to build the source code project), we only need to add the following files to the PDFReader project.

FoxitRDK.aar – contains JAR package which includes all the Java APIs of Foxit PDF SDK for Android, as well as the underlying “.so” libraries. The “.so” library is the heart of the SDK including the core functionalities of Foxit PDF SDK for Android. It is built separately for each architecture, and currently available for armeabi-v7a, arm64-v8a, x86, and x86_64.
FoxitRDKUIExtensions.aar – generated by the “uiextensions_src” project found in the “libs” folder. It includes the JAR package, built-in UI implementation, and resource files that are needed for the built-in UI implementations, such as images, strings, color values, layout files, and other Android UI resources.

Tip: The UI Extensions Component (FoxitRDKUIExtensions.aar) are not required for the following three sections “Initialize Foxit PDF SDK for Android“, “Display a PDF document using PDFViewCtrl“ and “Open a RMS protected document“, so you can just add FoxitRDK.aar to the project at first. Then, add FoxitRDKUIExtensions.aar when you need to use the UI Extensions Component, such like the project described in the section “Build a full-featured PDF Reader with UI Extensions Component“.

To add the above two AAR files into PDFReader project, please switch to the “Project” view panel and then follow the steps below:

a) Copy and paste the “FoxitRDK.aar” and “FoxitRDKUIExtensions.aar” files from the “libs” folder of the download package to “PDFReader\app\libs” folder.

Note: If you want to support Microsoft RMS, you also need to copy and paste the “RMSSDK-4.2-release.aar” and “rms-sdk-ui.aar” files from the “libs” folder to “PDFReader\app\libs” folder.

Synchronize PDFReader project, and then it should look like Figure 3-5.

Figure 3-5

b) Define the “libs” directory as a repository. Inside the app’s “build.gradle” file, add the following configuration:

build.gradle:
repositories {
    flatDir {
        dirs 'libs'
    }
}

c) Include Foxit PDF SDK for Android as a dependency in the project. Inside the app’s “build.gradle”, add “FoxitRDK.aar“, “FoxitRDKUIExtensions.aar” and the related support libraries to the dependencies. For simplicity, update the dependencies for example as follows:

dependencies {
    implementation(name: 'FoxitRDK', ext: 'aar')
    implementation(name: 'FoxitRDKUIExtensions', ext: 'aar')
    implementation 'com.android.support:design:27.1.1'
    implementation 'com.android.support:multidex:1.0.+'
    implementation 'com.edmodo:cropper:1.0.1'
    implementation('com.microsoft.aad:adal:1.1.16') {}
    implementation(name: 'RMSSDK-4.2-release', ext: 'aar')
    implementation(name: 'rms-sdk-ui', ext: 'aar')
    implementation "io.reactivex.rxjava2:rxjava:2.2.2"
    implementation 'io.reactivex.rxjava2:rxandroid:2.1.0'
    implementation 'org.bouncycastle:bcpkix-jdk15on:1.60'
    implementation 'org.bouncycastle:bcprov-jdk15on:1.60'

    implementation 'com.android.support:appcompat-v7:27.1.1'
    implementation 'com.android.support.constraint:constraint-layout:1.1.2'
    testImplementation 'junit:junit:4.12'
}

Note:

(Required) Foxit PDF SDK for Android has a dependency on recyclerview support library, so you should add it to the dependencies. In this project, we add ‘com.android.support:design:27.1.1′ which has already included the recyclerview package to the dependencies. Or you can add “implementation ‘com.android.support:recyclerview-v7:27.1.1′” directly.
(Optional) If you want to use the Snapshot feature (such as in the Complete PDF viewer demo, click at the right top toolbar, then you can see the Snapshot option), you should add “implementation ‘com.edmodo:cropper:1.0.1’” to the dependencies.
(Optional) If you want to open a RMS protected PDF file, you should add the following entries to the dependencies:

implementation('com.microsoft.aad:adal:1.1.16') {}
implementation(name: 'RMSSDK-4.2-release', ext: 'aar')
implementation(name: 'rms-sdk-ui', ext: 'aar')

Note: You had better use the verson of RMS SDK 4.2 and ADAL 1.1.16, otherwise there may cause compatibility issues.

(Optional) If you want to use the comparison feature (such as in the start screen of Complete PDF viewer demo, click at the right top toolbar, then you can see the comparison feature button), you should add the following entries to the dependencies:

implementation "io.reactivex.rxjava2:rxjava:2.2.2"
implementation 'io.reactivex.rxjava2:rxandroid:2.1.0'

(Optional) If you want to use the signature feature, you should add the following entries to the dependencies:

implementation 'org.bouncycastle:bcpkix-jdk15on:1.60'
implementation 'org.bouncycastle:bcprov-jdk15on:1.60'

Here, we add all the above support libraries to the dependencies, because later we will build a full-featured PDF Reader which contains all the features provided by Foxit PDF SDK for Android. After setting the app’s “build.gradle” file, sync it, then the “FoxitRDK.aar“, “FoxitRDKUIExtensions.aar“, “recyclerview“, “cropper“, “rxjava“, “rxandroid“ , “bcpkix-jdk15on“, “bcprov-jdk15on“ and RMS related pacakges will appear in External Libraries as shown in Figure 3-6.

Figure 3-6

The following code shows “build.gradle” in its entirety.

build.gradle:

apply plugin: 'com.android.application'

android {
    compileSdkVersion 27
    defaultConfig {
        applicationId "com.foxit.pdfreader"
        minSdkVersion 16
        targetSdkVersion 27
        versionCode 1
        versionName "1.0"


        multiDexEnabled true
        testInstrumentationRunner "android.support.test.runner.AndroidJUnitRunner"
    }
    buildTypes {
        release {
            minifyEnabled false
            proguardFiles getDefaultProguardFile('proguard-android.txt'), 'proguard-rules.pro'
        }
    }
}

repositories {
    flatDir {
        dirs 'libs'
    }
}

dependencies {
    implementation(name: 'FoxitRDK', ext: 'aar')
    implementation(name: 'FoxitRDKUIExtensions', ext: 'aar')
    implementation 'com.android.support:design:27.1.1'
    implementation 'com.android.support:multidex:1.0.+'
    implementation 'com.edmodo:cropper:1.0.1'
    implementation('com.microsoft.aad:adal:1.1.16') {}
    implementation(name: 'RMSSDK-4.2-release', ext: 'aar')
    implementation(name: 'rms-sdk-ui', ext: 'aar')
    implementation "io.reactivex.rxjava2:rxjava:2.2.2"
    implementation 'io.reactivex.rxjava2:rxandroid:2.1.0'
    implementation 'org.bouncycastle:bcpkix-jdk15on:1.60'
    implementation 'org.bouncycastle:bcprov-jdk15on:1.60'

    implementation 'com.android.support:appcompat-v7:27.1.1'
    implementation 'com.android.support.constraint:constraint-layout:1.1.2'
    testImplementation 'junit:junit:4.12'
}

Note So far, we set the compileSdkVersion and targetSdkVersion to API 27. If you also want to use API 27, please make sure you have already installed the SDK Platform Android 8.1, API 27. If you have not already done this, open the Android SDK Manager to download and install it first.

Initialize Foxit PDF SDK for Android

It is necessary for apps to initialize and unlock Foxit PDF SDK for Android using a license before calling any APIs. The function Library.initialize(sn, key) is provided to initialize Foxit PDF SDK for Android. The trial license files can be found in the “libs” folder of the download package. After the evaluation period expires, you should purchase an official license to continue using it. Below you can see an example of how to unock the SDK library. The next section will show you where to include this code in the PDFReader project.

import com.foxit.sdk.common.Constants;
import com.foxit.sdk.common.Library;
...

int errorCode = Library.initialize("sn", "key");
if (errorCode != Constants.e_ErrSuccess)
    return;

Note The parameter “sn” can be found in the “rdk_sn.txt” (the string after “SN=”) and the “key” can be found in the “rdk_key.txt” (the string after “Sign=”).

Display a PDF document using PDFViewCtrl

So far, we have added Foxit PDF SDK for Android libraries to the PDFReader project, and finished the initialization of the Foxit PDF SDK. Now, let’s start displaying a PDF document using PDFViewCtrl with just a few lines of code.

Note: The UI Extensions Component is not required if you only want to display a PDF document.

To display a PDF document, please follow the steps below:

a) Instantiate a PDFViewCtrl object to show an existing document.

In MainActivity.java, instantiate a PDFViewCtrl object, and call PDFViewCtrl.openDoc function to open and render the PDF document.

import com.foxit.sdk.PDFViewCtrl;
...
private PDFViewCtrl pdfViewCtrl = null;
...

pdfViewCtrl = new PDFViewCtrl(this);

String path = "/mnt/sdcard/input_files/Sample.pdf";
pdfViewCtrl.openDoc(path, null);

SetContentView(pdfViewCtrl);

Note: Please make sure you have pushed the “Sample.pdf” document into the created folder “input_files” of the Android device or emulator that will be used to run this project.

Update MainActivity.java as follows:

package com.foxit.pdfreader;

import android.support.v7.app.AppCompatActivity;
import android.os.Bundle;

import com.foxit.sdk.PDFViewCtrl;
import com.foxit.sdk.common.Constants;
import com.foxit.sdk.common.Library;

public class MainActivity extends AppCompatActivity {

    private PDFViewCtrl pdfViewCtrl = null;

    // The value of "sn" can be found in the "rdk_sn.txt".
    // The value of "key" can be found in the "rdk_key.txt".
    private static String sn = " ";
    private static String key = " ";

    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);

        // initialize the library.
        int errorCode = Library.initialize(sn, key);
        if (errorCode != Constants.e_ErrSuccess)
            return;

        pdfViewCtrl = new PDFViewCtrl(this);
        String path = "/mnt/sdcard/input_files/Sample.pdf";
        pdfViewCtrl.openDoc(path, null);

        setContentView(pdfViewCtrl);
    }
}

b) Set permissions to write and read the SD card of the Android devices or emulators.

Note: If you want to run this project on an Android 6.0 (API 23) or higher devices/emulators, you can do one of the following:

1) Change the targetSdkVersion in app’s “build.gradle” from 27 to the SDK version that is less than 23, such as 21.

2) Write additional code to require the authorization of runtime permissions.

a) Change the targetSdkVersion in app’s “build.gradle” from 27 to 21.

In this case, set the “users-permission” in the “AndroidManifest.xml” found in the “app/src/main” to give the project permission to write and read the SD card of the Android devices or emulators.

Update the AndroidManifest.xml as follows:

<?xml version="1.0" encoding="utf-8"?>
<manifest xmlns:android="http://schemas.android.com/apk/res/android"
    package="com.foxit.pdfreader">

    <uses-permission android:name="android.permission.WRITE_EXTERNAL_STORAGE"/>
    <uses-permission android:name="android.permission.READ_EXTERNAL_STORAGE"/>

    <application
        android:allowBackup="true"
        android:icon="@mipmap/ic_launcher"
        android:label="@string/app_name"
        android:roundIcon="@mipmap/ic_launcher_round"
        android:supportsRtl="true"
        android:theme="@style/AppTheme">
        <activity android:name=".MainActivity">
            <intent-filter>
                <action android:name="android.intent.action.MAIN" />

                <category android:name="android.intent.category.LAUNCHER" />
            </intent-filter>
        </activity>
    </application>

</manifest>

b) Write additional code to require the authorization of runtime permissions.

In the MainActivity.java file, add the following code to require the authorization of runtime permissions:

import android.content.pm.PackageManager;
import android.os.Build;
import android.support.annotation.NonNull;
import android.support.v4.app.ActivityCompat;
import android.support.v4.content.ContextCompat;
...

private static final int REQUEST_EXTERNAL_STORAGE = 1;
private static final String[] PERMISSIONS_STORAGE = {
        Manifest.permission.READ_EXTERNAL_STORAGE,
        Manifest.permission.WRITE_EXTERNAL_STORAGE
};
...

// Require the authorization of runtime permissions.
 if (Build.VERSION.SDK_INT >= 23) {
    int permission = ContextCompat.checkSelfPermission(this.getApplicationContext(), Manifest.permission.WRITE_EXTERNAL_STORAGE);
    if (permission != PackageManager.PERMISSION_GRANTED) {
        ActivityCompat.requestPermissions(this, PERMISSIONS_STORAGE, REQUEST_EXTERNAL_STORAGE);
        return;
    }
}
...

@Override
public void onRequestPermissionsResult(int requestCode, @NonNull String[] permissions, @NonNull int[] grantResults) {
    if (requestCode == REQUEST_EXTERNAL_STORAGE && grantResults[0] == PackageManager.PERMISSION_GRANTED) {
        // Open and Reader a PDF document.
        String path = "/mnt/sdcard/input_files/Sample.pdf";
        pdfViewCtrl.openDoc(path, null);
        setContentView(pdfViewCtrl);
    } else {
        super.onRequestPermissionsResult(requestCode, permissions, grantResults);
    }
}

Then, the whole contents of MainActivity.java will be as follows:

package com.foxit.pdfreader;

import android.Manifest;
import android.content.pm.PackageManager;
import android.os.Build;
import android.support.annotation.NonNull;
import android.support.v4.app.ActivityCompat;
import android.support.v4.content.ContextCompat;
import android.support.v7.app.AppCompatActivity;
import android.os.Bundle;

import com.foxit.sdk.PDFViewCtrl;
import com.foxit.sdk.common.Constants;
import com.foxit.sdk.common.Library;

public class MainActivity extends AppCompatActivity {

    private PDFViewCtrl pdfViewCtrl = null;

    private static final int REQUEST_EXTERNAL_STORAGE = 1;
    private static final String[] PERMISSIONS_STORAGE = {
            Manifest.permission.READ_EXTERNAL_STORAGE,
            Manifest.permission.WRITE_EXTERNAL_STORAGE
    };

    // The value of "sn" can be found in the "rdk_sn.txt".
    // The value of "key" can be found in the "rdk_key.txt".
    private static String sn = " ";
    private static String key = " ";

    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);

        // Initialize the library.
        int errorCode = Library.initialize(sn, key);
        if (errorCode != Constants.e_ErrSuccess)
            return;

        // Instantiate a PDFViewCtrl object.
        pdfViewCtrl = new PDFViewCtrl(this);

        // Require the authorization of runtime permissions.
        if (Build.VERSION.SDK_INT >= 23) {
            int permission = ContextCompat.checkSelfPermission(this.getApplicationContext(), Manifest.permission.WRITE_EXTERNAL_STORAGE);
            if (permission != PackageManager.PERMISSION_GRANTED) {
                ActivityCompat.requestPermissions(this, PERMISSIONS_STORAGE, REQUEST_EXTERNAL_STORAGE);
                return;
            }
        }

        // Open and Render a PDF document.
        String path = "/mnt/sdcard/input_files/Sample.pdf";
        pdfViewCtrl.openDoc(path, null);
        setContentView(pdfViewCtrl);
    }

    @Override
    public void onRequestPermissionsResult(int requestCode, @NonNull String[] permissions, @NonNull int[] grantResults) {
        if (requestCode == REQUEST_EXTERNAL_STORAGE && grantResults[0] == PackageManager.PERMISSION_GRANTED) {
            // Open and Render a PDF document.
            String path = "/mnt/sdcard/input_files/Sample.pdf";
            pdfViewCtrl.openDoc(path, null);
            setContentView(pdfViewCtrl);
        } else {
            super.onRequestPermissionsResult(requestCode, permissions, grantResults);
        }
    }
}

In this section, we build and run the project on an AVD targeting 8.1 (API 27), and use the second method (require authorization of runtime permissions) to get the permissions to write and read the SD card of the emulator.

Now, we have finished building a simple Android app which uses Foxit PDF SDK for Android to display a PDF document with just a few lines of code. The next step is to run the project.

After building the project and installing APK on the emulator, tap Allow on the pop-up window to allow the project to access files on the device, and then you will see that the “Sample.pdf” document is displayed as shown in Figure 3-7. Now, this sample app has some basic PDF features, such as zooming in/out and page turning. Just have a try!

Figure 3-7

Open a RMS protected document

From version 6.2.1, Foxit PDF SDK for Android supports to open a PDF document protected by Micorosoft Rights Management (RMS).

To open a RMS protected document, you should notice the following key points:

1) Include RMS related libraries as a dependency in the project. Please refer to the section “Integrate Foxit PDF SDK for Android into your apps“.

2) Set the associated activity before opening a PDF document, because it has UI operations when opening a RMS protected document.

pdfViewCtrl.setAttachedActivity(activity);

3) Handle the activity result from the UI operations. Call the API “pdfViewCtrl.handleActivityResult()” on the related onActivityResult function.

@Override
protected void onActivityResult(int requestCode, int resultCode, Intent data) {
    pdfViewCtrl.handleActivityResult(requestCode, resultCode, data);
}

Based on the previous section “Display a PDF document using PDFViewCtrl“, update the whole contents of MainActivity.java as follows:

package com.foxit.pdfreader;

import android.Manifest;
import android.content.pm.PackageManager;
import android.os.Build;
import android.support.annotation.NonNull;
import android.support.v4.app.ActivityCompat;
import android.support.v4.content.ContextCompat;
import android.support.v7.app.AppCompatActivity;
import android.os.Bundle;

import com.foxit.sdk.PDFViewCtrl;
import com.foxit.sdk.common.Constants;
import com.foxit.sdk.common.Library;

public class MainActivity extends AppCompatActivity {

    private PDFViewCtrl pdfViewCtrl = null;

    private static final int REQUEST_EXTERNAL_STORAGE = 1;
    private static final String[] PERMISSIONS_STORAGE = {
            Manifest.permission.READ_EXTERNAL_STORAGE,
            Manifest.permission.WRITE_EXTERNAL_STORAGE
    };

    // The value of "sn" can be found in the "rdk_sn.txt".
    // The value of "key" can be found in the "rdk_key.txt".
    private static String sn = " ";
    private static String key = " ";

    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);

        // initialize the library.
        int errorCode = Library.initialize(sn, key);
        if (errorCode != Constants.e_ErrSuccess)
            return;

        // Instantiate a PDFViewCtrl object.
        pdfViewCtrl = new PDFViewCtrl(this);


        // Set the associated activity for RMS UI operations.
        pdfViewCtrl.setAttachedActivity(this);


        // Require the authorization of runtime permissions.
        if (Build.VERSION.SDK_INT >= 23) {
            int permission = ContextCompat.checkSelfPermission(this.getApplicationContext(), Manifest.permission.WRITE_EXTERNAL_STORAGE);
            if (permission != PackageManager.PERMISSION_GRANTED) {
                ActivityCompat.requestPermissions(this, PERMISSIONS_STORAGE, REQUEST_EXTERNAL_STORAGE);
                return;
            }
        }

        // Open and Render a PDF document.
        String path = "/mnt/sdcard/input_files/Sample_RMS.pdf";
        pdfViewCtrl.openDoc(path, null);
        setContentView(pdfViewCtrl);
    }

    @Override
    public void onRequestPermissionsResult(int requestCode, @NonNull String[] permissions, @NonNull int[] grantResults) {
        if (requestCode == REQUEST_EXTERNAL_STORAGE && grantResults[0] == PackageManager.PERMISSION_GRANTED) {
            // Open and Render a PDF document.
            String path = "/mnt/sdcard/input_files/Sample_RMS.pdf";
            pdfViewCtrl.openDoc(path, null);
            setContentView(pdfViewCtrl);
        } else {
            super.onRequestPermissionsResult(requestCode, permissions, grantResults);
        }
    }


    @Override
    protected void onActivityResult(int requestCode, int resultCode, Intent data) {
        pdfViewCtrl.handleActivityResult(requestCode, resultCode, data);
    }
}

Note: Please make sure you have pushed a RMS protected document for example “Sample_RMS.pdf” into the created folder “input_files” of the Android device or emulator that will be used to run this project.

After building the project and installing APK on the emulator, tap Allow on the pop-up window to allow the project to access files on the device, and then you will see the following window (Figure 3-8) which prompts you to input your organizational email, and later input the password, then you can open the RMS protected document.

Figure 3-8

Build a full-featured PDF Reader with UI Extensions Component

Foxit PDF SDK for Android comes with built-in UI design including the basic UI for app and the feature modules UI, which are implemented using Foxit PDF SDK for Android and are shipped in the UI Extensions Component. Hence, building a full-featured PDF Reader is getting simpler and easier. All you need to do is to instantiate a UIExtensionsManager object, and then set it to PDFViewCtrl.

Instantiate a UIExtensionsManager object and set it to PDFViewCtrl

In “MainActivity.java” file, we are now going to add the code necessary for including the UIExtensionsManager. The required code additions are shown below and further down you will find a full example of what the “MainActivity.java” file should look like.

a) Set the system theme to “No Title” mode and set the window to Fullscreen.

Note: The UI Extensions Component has customized the user interface, so you need to set the system theme to “No Title” mode and set the window to Fullscreen. Otherwise, the layout of the built-in features might be affected.

import android.view.Window;
import android.view.WindowManager;


...
// Turn off the title at the top of the screen.
this.requestWindowFeature(Window.FEATURE_NO_TITLE);
// Set the window to Fullscreen.
getWindow().setFlags(WindowManager.LayoutParams.FLAG_FULLSCREEN, WindowManager.LayoutParams.FLAG_FULLSCREEN);

b) Add code to instantiate a UIExtensionsManager object and set it to PDFViewCtrl.

import com.foxit.uiextensions.UIExtensionsManager;


...
private UIExtensionsManager uiExtensionsManager = null;


...
uiExtensionsManager = new UIExtensionsManager(this.getApplicationContext(), pdfViewCtrl);
uiExtensionsManager.setAttachedActivity(this);
uiExtensionsManager.onCreate(this, pdfViewCtrl, savedInstanceState);
pdfViewCtrl.setUIExtensionsManager(uiExtensionsManager);

c) Open and render a PDF document, and set the content view.

Call UIExtensionsManager.openDocument() function to open and render a PDF document instead of calling PDFViewCtrl.openDoc() function.

import com.foxit.uiextensions.UIExtensionsManager;


...
String path = "/mnt/sdcard/input_files/Sample.pdf";
uiExtensionsManager.openDocument(path, null);
setContentView(uiExtensionsManager.getContentView());

Update MainActivity.java as follows:

Note: The Activity Lifecycle Events should be handled as below, otherwise some features may not work correctly.

package com.foxit.pdfreader;

import android.Manifest;
import android.content.pm.PackageManager;
import android.content.res.Configuration;
import android.os.Build;
import android.support.annotation.NonNull;
import android.support.v4.app.ActivityCompat;
import android.support.v4.content.ContextCompat;
import android.support.v7.app.AppCompatActivity;
import android.os.Bundle;
import android.view.KeyEvent;
import android.view.Window;
import android.view.WindowManager;


import com.foxit.sdk.PDFViewCtrl;
import com.foxit.sdk.common.Constants;
import com.foxit.sdk.common.Library;
import com.foxit.uiextensions.UIExtensionsManager;

public class MainActivity extends AppCompatActivity {

    private PDFViewCtrl pdfViewCtrl = null;
    private UIExtensionsManager uiExtensionsManager = null;

    private static final int REQUEST_EXTERNAL_STORAGE = 1;
    private static final String[] PERMISSIONS_STORAGE = {
            Manifest.permission.READ_EXTERNAL_STORAGE,
            Manifest.permission.WRITE_EXTERNAL_STORAGE
    };

    // The value of "sn" can be found in the "rdk_sn.txt".
    // The value of "key" can be found in the "rdk_key.txt".
    private static String sn = " ";
    private static String key = " ";

    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);

        // initialize the library.
        int errorCode = Library.initialize(sn, key);
        if (errorCode != Constants.e_ErrSuccess)
            return;
        // Turn off the title at the top of the screen.
        this.requestWindowFeature(Window.FEATURE_NO_TITLE);
        // Set the window to Fullscreen.
        getWindow().setFlags(WindowManager.LayoutParams.FLAG_FULLSCREEN, WindowManager.LayoutParams.FLAG_FULLSCREEN);

        // Instantiate a PDFViewCtrl object.
        pdfViewCtrl = new PDFViewCtrl(this);

        // Set the associated activity for RMS UI operations.
        pdfViewCtrl.setAttachedActivity(this);
        // Initialize a UIExtensionManager object and set it to PDFViewCtrl.
        uiExtensionsManager = new UIExtensionsManager(this.getApplicationContext(), pdfViewCtrl);
        uiExtensionsManager.setAttachedActivity(this);
        uiExtensionsManager.onCreate(this, pdfViewCtrl, savedInstanceState);
        pdfViewCtrl.setUIExtensionsManager(uiExtensionsManager);

        // Require the authorization of runtime permissions.
        if (Build.VERSION.SDK_INT >= 23) {
            int permission = ContextCompat.checkSelfPermission(this.getApplicationContext(), Manifest.permission.WRITE_EXTERNAL_STORAGE);
            if (permission != PackageManager.PERMISSION_GRANTED) {
                ActivityCompat.requestPermissions(this, PERMISSIONS_STORAGE, REQUEST_EXTERNAL_STORAGE);
                return;
            }
        }

        // Open and Render a PDF document.
        String path = "/mnt/sdcard/input_files/Sample.pdf";
        uiExtensionsManager.openDocument(path, null);
        setContentView(uiExtensionsManager.getContentView());
    }

    @Override
    public void onRequestPermissionsResult(int requestCode, @NonNull String[] permissions, @NonNull int[] grantResults) {
        if (requestCode == REQUEST_EXTERNAL_STORAGE && grantResults[0] == PackageManager.PERMISSION_GRANTED) {
            // Open and Render a PDF document.
            String path = "/mnt/sdcard/input_files/Sample.pdf";
            uiExtensionsManager.openDocument(path, null);
            setContentView(uiExtensionsManager.getContentView());
        } else {
            super.onRequestPermissionsResult(requestCode, permissions, grantResults);
        }
    }
    @Override
    protected void onActivityResult(int requestCode, int resultCode, Intent data) {
        pdfViewCtrl.handleActivityResult(requestCode, resultCode, data);
    }

    @Override
    public void onStart() {
        if (uiExtensionsManager != null) {
            uiExtensionsManager.onStart(this);
        }
        super.onStart();
    }

    @Override
    public void onStop() {
        if (uiExtensionsManager != null) {
            uiExtensionsManager.onStop(this);
        }
        super.onStop();
    }

    @Override
    public void onPause() {
        if (uiExtensionsManager != null) {
            uiExtensionsManager.onPause(this);
        }
        super.onPause();
    }

    @Override
    public void onResume() {
        if (uiExtensionsManager != null) {
            uiExtensionsManager.onResume(this);
        }
        super.onResume();
    }

    @Override
    protected void onDestroy() {
        if (uiExtensionsManager != null) {
            uiExtensionsManager.onDestroy(this);
        }
        super.onDestroy();
    }

    @Override
    public void onConfigurationChanged(Configuration newConfig) {
        super.onConfigurationChanged(newConfig);
        if (uiExtensionsManager != null) {
            uiExtensionsManager.onConfigurationChanged(this, newConfig);
        }
    }

    @Override
    public boolean onKeyDown(int keyCode, KeyEvent event) {
        if (uiExtensionsManager != null && uiExtensionsManager.onKeyDown(this, keyCode, event))
            return true;
        return super.onKeyDown(keyCode, event);
    }
}

Update AndroidManifest.xml

Add “<uses-permission android:name=“android.permission.CAMERA”/>” to grant the project permissions to access the camera.

Add “<uses-permission android:name=“android.permission.RECORD_AUDIO”/>” to grant the project permissions to record audio or video. If you do not add it, the audio and video features will not work correctly.

Add “<uses-permission android:name=“android.permission.SYSTEM_ALERT_WINDOW”/>” to grant your phone the floating window permissions. If you do not add this permission, the Pan and Zoom feature will not be able to work.

Add “android:configChanges=“keyboardHidden|orientation|locale|layoutDirection|screenSize”>” property to make sure that the project will only execute the onConfigurationChanged() function without recalling the activity lifecycle when rotating the screen. If you do not add this property, the signature feature will not work correctly.

Update AndroidManifest.xml as follows:

<?xml version="1.0" encoding="utf-8"?>
<manifest xmlns:android="http://schemas.android.com/apk/res/android"
    package="com.foxit.pdfreader">

    <uses-permission android:name="android.permission.CAMERA" />
    <uses-permission android:name="android.permission.RECORD_AUDIO" />


    <uses-permission android:name="android.permission.SYSTEM_ALERT_WINDOW" />

    <application
        android:allowBackup="true"
        android:icon="@mipmap/ic_launcher"
        android:label="@string/app_name"
        android:roundIcon="@mipmap/ic_launcher_round"
        android:supportsRtl="true"
        android:theme="@style/AppTheme">
        <activity android:name=".MainActivity"
         android:configChanges="keyboardHidden|orientation|locale|layoutDirection|screenSize">
            <intent-filter>
                <action android:name="android.intent.action.MAIN" />

                <category android:name="android.intent.category.LAUNCHER" />
            </intent-filter>
        </activity>
    </application>

</manifest>

Run the project

In this section, we build and run the project on an AVD targeting Android 8.1 (API 27). After building the project and installing APK on the emulator, tap Allow on the pop-up window to allow the project to access files on the device, and then you will see that the “Sample.pdf” document is displayed as shown in Figure 3-9. Up to now, it is a full-featured PDF Reader which includes all of the features in Complete PDF viewer demo and it also supports to open a RMS protected document. Feel free to try it.

Figure 3-9

Customizing User Interface

Foxit PDF SDK for Android provides a simple, clean and friendly user interface for developers to quickly build a full-featured PDF app without needing to take much time on the design. Furthermore, customizing the user interface is straightforward. Foxit PDF SDK for Android provides the source code of the UI Extensions Component that contains ready-to-use UI module implementations, which lets the developers have full control of styling the appearance as desired.

From version 4.0, developers can flexibly customize the features they want through a configuration file.

From version 5.0, every element in the built-in UI can be configurable. More advanced APIs and more powerful configuration file are provided for developers to further customize the UI elements, such as showing or hiding a specific panel, top/bottom toolbar, the items in the top/bottom toolbar, and the items in the View setting bar and More Menu view.

From version 6.3, the configuration file has been enhanced which provides more optional settings to customize the UI including the rights management and the properties of UI elements.

The following section will introduce how to customize the feature modules, rights management and UI elements through a configuration file, or APIs, or the source code.

Customize the UI through a configuration file

Through a configuration file, developers can easily choose the feature modules, set the rights management and the properties of UI elements without needing to write any additional code or redesign the app’s UI.

Introduction to JSON file

The configuration file can be provided as a JSON file or implemented directly in code. We recommend you to use the JSON format which is more intuitive and clearer to view and configure the items.

You can refer to the JSON file found in “samples\complete_pdf_viewer\app\src\main\res\raw” folder of Foxit PDF SDK for Android package. It looks like as follows:

{
    "modules": {
        "readingbookmark": true,
        "outline": true,
//        "annotations":true,
        "annotations": {
            "highlight": true,
            "underline": true,
            "squiggly": true,
            "strikeout": true,
            "insert": true,
            "replace": true,
            "line": true,
            "rectangle": true,
            "oval": true,
            "arrow": true,
            "pencil": true,
            "eraser": true,
            "typewriter": true,
            "textbox": true,
            "callout": true,
            "note": true,
            "stamp": true,
            "polygon": true,
            "cloud": true,
            "polyline": true,
            "distance": true,
            "image": true,
            "audio": true,
            "video": true,
            "redaction": true
        },
        "thumbnail": true,
        "attachment": true,
        "signature": true,
        "search": true,
        "navigation": true,
        "form": true,
        "selection": true,
        "encryption": true
        "multipleSelection": true
    },
    "permissions": {
         "runJavaScript": true,
         "copyText": true,
         "disableLink": false
    },
    "uiSettings": {
      "pageMode": "Single",
      "continuous": false,
      "reflowBackgroundColor": "#FFFFFF",
      "zoomMode": "FitWidth",
      "colorMode": "Normal",
      "mapForegroundColor": "#5d5b71",
      "mapBackgroundColor": "#00001b",
      "disableFormNavigationBar": false,
      "highlightForm": true,
      "highlightFormColor": "#200066cc",
      "highlightLink": true,
      "highlightLinkColor": "#16007fff",
      "fullscreen": true,
      "annotations": {
               "continuouslyAdd": false,
                "highlight": {
                  "color": "#ffff00", "opacity": 1.0
                },
                "underline": {
                  "color": "#66cc33", "opacity": 1.0
                },
                "squiggly": {
                  "color": "#ff6633", "opacity": 1.0
                },
                "strikeout": {
                  "color": "#ff0000", "opacity": 1.0
                },
                "insert": {
                  "color": "#993399", "opacity": 1.0
                },
                "replace": {
                  "color": "#0000ff", "opacity": 1.0
                },
                "line": {
                  "color": "#ff0000", "opacity": 1.0, "thickness": 2
                },
                "rectangle": {
                  "color": "#ff0000", "opacity": 1.0, "thickness": 2
                },
                "oval": {
                  "color": "#ff0000", "opacity": 1.0, "thickness": 2
                },
                "arrow": {
                  "color": "#ff0000", "opacity": 1.0, "thickness": 2
                },
                "pencil": {
                  "color": "#ff0000", "opacity": 1.0, "thickness": 2
                },
                "polygon": {
                  "color": "#ff0000", "opacity": 1.0, "thickness": 2
                },
                "cloud": {
                  "color": "#ff0000", "opacity": 1.0, "thickness": 2
                },
                "polyline": {
                  "color": "#ff0000", "opacity": 1.0, "thickness": 2
                },
                "typewriter": {
                  "textColor": "#0000ff",
                  "opacity": 1.0,
                  "textFace": "Courier",
                  "textSize": 18
                },
                "textbox": {
                  "color": "#ff0000",
                  "textColor": "#0000ff",
                  "opacity": 1.0,
                  "textFace": "Courier",
                  "textSize": 18
                },
                "callout": {
                  "color": "#ff0000",
                  "textColor": "#0000ff",
                  "opacity": 1.0,
                  "textFace": "Courier",
                  "textSize": 18
                },
                "note": {
                  "color": "#ff6633",
                  "opacity": 1.0,
                  "icon": "Comment"
                },
                "attachment": {
                  "color": "#ff6633",
                  "opacity": 1.0,
                  "icon": "PushPin"
                },
                "image": {
                   "rotation": 0,
                  "opacity": 1.0
                },
                "distance": {
                   "color": "#ff0000",
                   "opacity": 1.0,
                   "thickness": 2,
                   "scaleFromUnit": "inch",
                   "scaleToUnit": "inch",
                   "scaleFromValue": 1,
                   "scaleToValue": 1
                },
                "redaction": {
                   "fillColor": "#000000",
                   "textColor": "#ff0000",
                   "textFace": "Courier",
                   "textSize": 12
                }
        },
        "signature": {
            "color": "#000000", "thickness": 8
        }
    }
}

Note:

The values in the above JSON file are the default settings for the configuration items. If some configuration items are not in the JSON file, the default settings will be used. For example, if you comment out ““highlight”: true,“, it is still enabled.
Only the attachment annotation in the Annotation setting bar is not controlled by the subitems in “annotations“. Click Comment at the bottom toolbar to show the Annotation setting bar, and then long press the (Note) to find the attachment annotation, which is as shown in Figure 4-1.

““attachment”: true,” controls the attachments panel and attachment annotation. If you set it to “false”, both of them will be disabled. If you want to hide “Comment” in the bottom toolbar, you should set both “annotations“ and “attachment” to “false“.

Figure 4-1

Configuration Items Description

The JSON configuration file includes three parts: feature modules, rights management, and UI settings (for example, UI elements properties). This section will set forth the configuration items in detail.

Configure feature module

Note: The value type of the feature module items is bool, where “true” means that the feature module will be enabled, and “false” means that the feature module will be disabled. The default value is “true”.

Feature Module	Description
readingbookmark	User-defined bookmark
outline	PDF document bookmark
annotations (highlight, underline, squiggly, strikeout, insert, replace, line, rectangle, oval, arrow, pencil, eraser, typewriter, textbox, callout, note, stamp, polygon, cloud, polyline, distance, image, audio, video, redaction)	Annotation module collection
thumbnail	PDF page thumbnail display and page management
attachment	PDF document attachments
signature	Digital signatures and handwritten signatures
search	Text search
navigation	PDF page navigation
form	Form Filling and form data importing and exporting
selection	Text selection
encryption	PDF encryption
multipleSelection	Multiple annotations selection

Configure rights management

Note: The value type of the configuration items is bool, where “true” means that the permission will be enabled, and “false“ means that the permission will be disabled. The default value of runJavaScript and copyText is “true”, and the default value of disableLink is “false”.

Rights Management	Description
runJavaScript	whether to allow to execute JavaScript
copyText	whether to allow to copy text
disableLink	whether to disable hyperlink

Configure UI settings

UI Items	Description/ Property Items	Value Type	Available Value	Default value	Note
pageMode	Page display mode	String	Single/ Facing/ CoverLeft/ CoverMiddle/ CoverRight/ Reflow	Single	For dynamic XFA files, it doesn’t support Reflow mode.
continuous	Whether to view pages continuously	Bool	true/false	false	True means continuous pages, false means discontinuous pages. It is invalid for “Reflow” mode.
reflowBackgroundColor	Background color of reflow page	RGB	—	#FFFFFF
zoomMode	Page zoom mode	String	FitWidth/FitPage	FitWidth
colorMode	Page color display mode	String	Normal/Night/Map	Normal	“Night” is a special “Map” mode.
mapForegroundColor	Foreground color of page display	RGB	—	#5d5b71	It is vaild only when “colorMode” is set to “Map”.
mapBackgroundColor	Background color of page dispay	RGB	—	#00001b	It is vaild only when “colorMode” is set to “Map”.
disableFormNavigationBar	Whether to disable the supplementary navigation bar of the form	Bool	true/false	false
highlightForm	Whether to highlight form field	Bool	true/false	true
highlightFormColor	The highlight color of forms	ARGB		#200066cc	It include alpha channel, and it is invalid for dynamic xfa document.
highlightLink	Whether to highlight hyperlink	Bool	true/false	true
highlightLinkColor	The highlight color of links	ARGB		#16007fff	It include alpha channel.
fullscreen	Whether to display in full screen mode	Bool	true/false	true	It will be in full screen mode immediately when opening a document if “fullscreen” is set to “true”. If the user clicks on the page, the toolbar will be displayed. After 5 seconds, if it is in full screen mode, the toolbar and other auxiliary tool buttons will be hidden automatically.
annotations	continuouslyAdd		Bool	true/false	false	Whether to add annotation continuously
	highlight	color	RGB		#ffff00
		opacity	numeric	[0.0-1.0]	1.0
	underline	color	RGB		#66cc33
		opacity	numeric	[0.0-1.0]	1.0
	squiggly	color	RGB		#ff6633
		opacity	numeric	[0.0-1.0]	1.0
	strikeout	color	RGB		#ff0000
		opacity	numeric	[0.0-1.0]	1.0
	insert	color	RGB		#993399
		opacity	numeric	[0.0-1.0]	1.0
	replace	color	RGB		#0000ff
		opacity	numeric	[0.0-1.0]	1.0
	line	color	RGB		#ff0000
		opacity	numeric	[0.0-1.0]	1.0
		thickness	numeric	[1-12]	2
	rectangle	color	RGB		#ff0000
		opacity	numeric	[0.0-1.0]	1.0
		thickness	numeric	[1-12]	2
	oval	color	RGB		#ff0000
		opacity	numeric	[0.0-1.0]	1.0
		thickness	numeric	[1-12]	2
	arrow	color	RGB		#ff0000
		opacity	numeric	[0.0-1.0]	1.0
		thickness	numeric	[1-12]	2
	pencil	color	RGB		#ff0000
		opacity	numeric	[0.0-1.0]	1.0
		thickness	numeric	[1-12]	2
	polygon	color	RGB		#ff0000
		opacity	numeric	[0.0-1.0]	1.0
		thickness	numeric	[1-12]	2
	cloud	color	RGB		#ff0000
		opacity	numeric	[0.0-1.0]	1.0
		thickness	numeric	[1-12]	2
	polyline	color	RGB		#ff0000
		opacity	numeric	[0.0-1.0]	1.0
		thickness	numeric	[1-12]	2
	typewriter	textColor	RGB		#0000ff
		opacity	numeric	[0.0-1.0]	1.0
		textFace	String	Courier/ Helvetica/ Times	Courier	Text font name. If set to an invalid value, the default value will be used.
		textSize	Integer	>=1	18
	textbox	color	RGB		#ff0000
		textColor	RGB		#0000ff
		opacity	numeric	[0.0-1.0]	1.0
		textFace	String	Courier/ Helvetica/ Times	Courier	Text font name. If set to an invalid value, the default value will be used.
		textSize	Integer	>=1	18
	callout	color	RGB		#ff0000
		textColor	RGB		#0000ff
		opacity	numeric	[0.0-1.0]	1.0
		textFace	String	Courier/ Helvetica/ Times	Courier	Text font name. If set to an invalid value, the default value will be used.
		textSize	Integer	>=1	18
	note	color	RGB		#ff6633
		opacity	numeric	[0.0-1.0]	1.0
		icon	String	Comment/ Key/ Note/ Help/ NewParagraph/ Paragraph/ Insert	Comment	If set to an invalid value, the default value will be used.
	attachment	color	RGB		#ff6633
		opacity	numeric	[0.0-1.0]	1.0
		icon	String	Graph/ PushPin/ Paperclip/ Tag	PushPin	If set to an invalid value, the default value will be used.
	image	rotation	numeric	0/90/180/270	0
		opacity	numeric	[0.0-1.0]	1.0
	distance	color	RGB		#ff0000
		opacity	numeric	[0.0-1.0]	1.0
		thickness	numeric	[1-12]	2
		scaleFromUnit	String	pt/m/cm/mm/inch/p/ft/yd	inch	The original unit of the scale
		scaleToUnit	String	pt/m/cm/mm/inch/p/ft/yd	inch	The target unit of the scale
		scaleFromValue	numeric		1	The original value of the scale
		scaleToValue	numeric		1	The target value of the scale
	redaction	fillColor	RGB		#000000
		textColor	RGB		#ff0000
		textFace	String	Courier/ Helvetica/ Times	Courier	Text font name. If set to an invalid value, the default value will be used.
		textSize	Integer	>=1	12
signature	color	RGB		#000000
	thickness	numeric	[1-12]	8

Instantiate a UIExtensionsManager object with the configuration file

We have already introduced how to instantiate UIExtensionsManager, and in this way all the built-in UI framework would be loaded by default. In this section, we will provide another method to instantiate UIExtensionsManager that uses the configuration file, so that developers can easily customize the UI as desired.

Please refer to the following code to instantiate a UIExtensionsManager object with the configuration file.

Note: Here, we assume that you have already put a JSON file named “uiextensions_config.json” to “PDFReader\app\src\main\res\raw” (note that you need to create the “raw” folder by yourself).

In “MainActivity.java”:

import com.foxit.uiextensions.config.Config;
...

private PDFViewCtrl pdfViewCtrl = null;
private UIExtensionsManager uiExtensionsManager = null;
// Initialize a PDFViewCtrl object.
pdfViewCtrl = new PDFViewCtrl(this);

// Get the config file, and set it to UIExtensionsManager.
InputStream stream = this.getApplicationContext().getResources().openRawResource(R.raw.uiextensions_config);
Config config = new Config(stream);

// Initialize a UIExtensionManager object with Configuration file, and set it to PDFViewCtrl.
uiExtensionsManager = new UIExtensionsManager(this.getApplicationContext(), pdfViewCtrl,config);
pdfViewCtrl.setUIExtensionsManager(uiExtensionsManager);
uiExtensionsManager.setAttachedActivity(this);
uiExtensionsManager.onCreate(this, pdfViewCtrl, savedInstanceState);

Note: Here, we use a configuration file to instantiate the UIExtensionsManager. If you do not want to use configuration file, please refer to an earlier section.

Examples for customizing UI through a configuration file

In this section, we will show you how to customize feature modules, rights management and UI settings (for example, UI elements properties) in your project. You will find it is extremely easy! You only need to modify the configuration file. Below you can see some examples of how to do it.

Note: For your convenience, we will try it in the “complete_pdf_viewer” demo found in the “samples” folder.

Load the “complete_pdf_viewer” demo in Android Studio. Find the configuration file “uiextensions_config.json” under “complete_pdf_viewer\app\src\main\res\raw”.

Example1: Disable “readingbookmark” and “navigation” feature modules.

In the JSON file, set the values of “readingbookmark” and “navigation” to “false” as follows:

"readingbookmark": false,
"navigation": false,

Then, rebuild and run the demo to see the result. Following lists the comparison diagrams:

Before:

After:

The “readingbookmark” and “navigation“ feature modules are removed.

Example2: Disable hyperlinks.

In the JSON file, set the value of “disableLink” to “true” as follows:

"permissions": {
     "runJavaScript": true,
     "copyText": true,
     "disableLink": true
},

Then, rebuild and run the demo to see the result, and you will find that there is no any response when clicking the hyperlinks.

Example3: Set the highlight color from yellow to red.

In the JSON file, set the color property of “highlight” to “#ff0000” as follows:

"highlight": {
  "color": "#ff0000", "opacity": 1.0 },

Then, rebuild and run the demo to see the result. Following lists the comparison diagrams:

Before:

After:

The highlight color has been changed to red.

Customize UI elements through APIs

In version 4.0, Foxit PDF SDK for Android supported customizing to show or hide the whole top or bottom toolbar, and from version 5.0, it provided APIs to customize to show or hide a specific panel, the items in the top/bottom toolbar, View setting bar and More Menu view, which is convenient for developers to modify the UI elements in the context of the built-in UI framework.

Note: For your convenience, we will show you how to customize UI elements through APIs in the “complete_pdf_viewer” demo found in the “samples” folder. We assume that you have not modified the “uiextensions_config.json” file in the demos, which means that all of the built-in UI in the UI Extensions Component are enabled.

Customizing top/bottom toolbar

In the top/bottom toolbar, you can do the following operations:

Show or hide the top/bottom toolbar.
Add a custom item at any position.
Remove a specific item.
Remove all of the items in the toolbar.
Show or hide a specific item.
Add a custom toolbar.
Remove a specific toolbar.
Set background color for the toolbar.
Get the number of the items in a specific location of the toolbar.

Table 4-1 lists the related APIs which are used to customize the top/bottom toolbar.

Table 4-1

void enableTopToolbar(boolean isEnabled)	Enable or disable top toolbar.
void enableBottomToolbar(boolean isEnabled)	Enable or disable bottom toolbar.
boolean addItem(BarName barName, BaseBar.TB_Position gravity, BaseItem item, int index);	Add a custom item to the toolbar.
boolean addItem(BarName barName, BaseBar.TB_Position gravity, int textId, int resId, int index, IItemClickListener clickListener);	Add a default item to the toolbar.
boolean addItem(BarName barName, BaseBar.TB_Position gravity, CharSequence text, int index, IItemClickListener clickListener);	Add a default text-only item to the toolbar.
boolean addItem(BarName barName, BaseBar.TB_Position gravity, Drawable drawable, int index, IItemClickListener clickListener);	Add a default image-only item to the toolbar.
IBaseItem getItemByIndex(BarName barName, BaseBar.TB_Position gravity, int index);	Get the item by index.
void setItemVisibility(BarName barName, BaseBar.TB_Position gravity, int index, int visibility);	Set the enabled state of this item view.
int getItemVisibility(BarName barName, BaseBar.TB_Position gravity, int index);	Returns the visibility status for this view.
int getItemsCount(BarName barName, BaseBar.TB_Position gravity);	Get the items count by IBarsHandler.BarName and BaseBar.TB_Position.
boolean removeItem(BarName barName, BaseBar.TB_Position gravity, int index);	Remove the item at the specified position in the toolbar.
boolean removeItem(BarName barName, BaseBar.TB_Position gravity, BaseItem item);	Remove the item by IBarsHandler.BarName, BaseBar.TB_Position and the specified item.
void removeAllItems(BarName barName);	Remove all items from the toolbar.
boolean addCustomToolBar(BarName barName, View view);	Add custom toolbar by BarName.
boolean removeToolBar(BarName barName);	Remove toolbar by BarName.
void setBackgroundColor(BarName barName, int color);	Set background color for the toolbar.
void setBackgroundResource(BarName barName, int resid);	Set background to a given resource.
BaseItem getItem(BarName barName, BaseBar.TB_Position gravity, int tag);	Get the item by tag, if tag does not exist, it return null.

There are two important enumerations which are defined to locate the position that you want to add a new item or remove an existing item.

enum BarName {
        TOP_BAR,
        BOTTOM_BAR;
    }

enum TB_Position {
        Position_LT,
        Position_CENTER,
        Position_RB;
    }

Note:

1) The top toolbar or bottom toolbar can only add up to 7 items.

2) To add an item to the top toolbar, please set the BaseBar.TB_Position to Position_LT or Position_RB. To add an item to the bottom toolbar, please set the BaseBar.TB_Position to Position_CENTER. Otherwise, the items may overlap.

3) The bottom toolbar is only one part, and the top toolbar is divided into two parts, so that there are three parts for the toolbar, and each part has a separate index.(See Figure 4-2)

4) For the best UI display, it is recommended to control the character number of text for top toolbar within 15 and for bottom toolbar within 8. If don’t, the view layout may be in disorder.

Figure 4-2

In the following examples, we will show you how to customize the top/bottom toolbar through APIs in the “complete_pdf_viewer” demo found in the “samples” folder.

Load the “complete_pdf_viewer” demo in Android Studio. Add the sample code to the “PDFReaderFragment.java” file (after the code “mUiExtensionsManager = new UIExtensionsManager(getActivity().getApplicationContext(), pdfViewerCtrl, config);”).

Example1: Hide the whole top toolbar.

mUiExtensionsManager.enableTopToolbar(false);

Before:

After:

Example2: Hide the whole bottom toolbar.

mUiExtensionsManager.enableBottomToolbar(false);

Before:
